Our Rail type laser cutting CNC machine is perfect for large plate cutting with its long rails. Place 2 or more plates together for continuous cutting from one plate to another.

Inquiry
Rail Type Fiber Laser Cutting CNC Machine
Rail Type Fiber Laser Cutting CNC Machine
Video And Gallery
CNC龍門式雷射切割機
Video
Gantry Type Fiber Laser Cutting CNC Machine
Gallery
Product Specifications
Model FSC-Laser 3000D x 15M FSC-Laser 4000D x 15M FSC-Laser 5000D x 15M
Laser Power You can choose from IPG, MAX, or Raycus laser power sources based on your needs;
Laser power: 6kw ~ 100kw.
Laser Cutting Head Can choose Precitec, Raytools laser cutting head brands according to needs.
Working Stroke X 2200 3200 4200
Y 12500
Z 150-250 depending on different laser power sources
Positioning Speed (m/min) 50
Positioning Accuracy (mm) 0.03
Rail center to Rail center (mm) 3000 4000 5000
Rail length (mm) 15M( can be shorter or longer according to needs)
Option Round Pipe/Round + Square Pipe Cutting
Option Bevel Cutting
